tibs 1.1.0

A sleek Python library for binary data

tibs is a Rust-backed Python library for binary data that does not assume everything fits neatly into bytes. Use it for packets, registers, instruction formats, bitsets, compressed data and streams where fields can have many different interpretations and be any number of bits long.

It is use to power the popular bitstring library, which is by the same author.

Install

pip install tibs

Tibs works with Python 3.10 and later. There are pre-built wheels for most common platforms; if there are issues then please let me know.

The full documentation is available on Read the Docs.

Why use it?

• It's fast - often significantly faster than similar libraries.
• Work with bit sequences of any length, not just whole bytes.
• Construct from strings, bytes, bools, integers, floats, random data or typed values.
• Slice, split and reinterpret fields as bytes, ints, floats, binary, octal or hex.
• Decode little-endian values and LSB0-labelled fields without manually reshuffling data.
• Search, count, replace, rotate, reverse, byte-swap, set and unset bits with Rust-backed operations.
• Use immutable Tibs for stable values and cheap slices; use Mutibs for in-place edits.

Quick taste

Tibs is immutable, like bytes. It is good for parsing, slicing, hashing and holding stable binary values.

>>> from tibs import Tibs
>>> # Four flag bits, a 12-bit integer, then two payload bytes.
>>> packet = Tibs.from_joined(["0b1010", Tibs.from_u(3200, 12), b"OK"])
>>> packet
Tibs('0xac804f4b')

>>> flags, size, payload = packet.split_at([4, 16])
>>> flags.bin, size.u, payload.bytes
('1010', 3200, b'OK')

>>> packet.find(b"OK", byte_aligned=True)
16

Mutibs is mutable. Convert when a packet or bitset needs to be patched in place.

>>> patched = packet.to_mutibs()
>>> patched[4:16] = Tibs.from_u(2047, 12)
>>> patched[-8:] = b"!"
>>> patched
Mutibs('0xa7ff4f21')
>>> patched[4:16].to_u(), patched[-16:].bytes
(2047, b'O!')
>>> packet
Tibs('0xac804f4b')

Views handle byte order and bit numbering. This is the sort of job that gets awkward quickly with plain bytes and masks.

>>> # Linux eBPF: little-endian instruction, LSB0 field labels.
>>> instruction = Tibs.from_bytes(bytes.fromhex("07 01 00 00 44 33 22 11")).lsb0.le
>>> dst_reg = instruction.field(11, 8).u
>>> immediate = instruction.field(63, 32).u
>>> f"r{dst_reg} += 0x{immediate:08x}"
'r1 += 0x11223344'

Search APIs work at bit granularity but can also stay byte-aligned for stream parsing.

>>> sync = Tibs("0xaa55")
>>> log = bytes.fromhex("00 ff aa 55 11 02 c0 01 7f aa 55 22 01 40 aa")
>>> bits = Tibs(log)
>>> records = []
>>> for start in bits.find_all_iter(sync, byte_aligned=True):
...     payload_len = bits[start + 24:start + 32].u
...     payload = bits[start + 32:start + 32 + payload_len * 8]
...     if len(payload) == payload_len * 8:
...         records.append((bits[start + 16:start + 24].u, payload.bytes))
>>> records
[(17, b'\xc0\x01'), (34, b'@')]

The full documentation covers construction from ints, floats, bytes and strings; endianness; searching and replacing; rotations; bit indexing; serialization; and worked examples.

Performance

Tibs is written in Rust with PyO3. The repository contains a dedicated performance regression suite and CI workflow that compare benchmark medians against the base commit.

The regression benchmarks cover operations such as:

• bit-pattern search, reverse search and byte-aligned search
• logical operations on large aligned and unaligned slices
• counting, inversion, shifting, reversing and concatenation
• bulk mutation, slice replacement, deletion, append and pop
• bytes conversion, random generation and bool-list construction
• typed packing and unpacking such as u16 value streams
• a sieve workload using Mutibs as a large mutable bitset

For local comparisons, tests/performance_comparison_new.py checks common operations against bitarray. With bitarray installed, run:

python tests/performance_comparison_new.py --bytes 250000 --values 20000 --repeats 5

Benchmarks are machine-dependent, but the mean speedup over bitarray will typically be > 2x.

Examples

The runnable examples in examples/ are small, but they are meant to look like real binary-data tasks:

Project status

Tibs has reached the 1.0 stable API milestone. Documented public behavior will remain compatible across future 1.x releases. It is used to power the bitstring library and gets several million downloads per month.

There are over 800 unit tests, including Hypothesis tests and performance benchmarks.

For the full API reference, see the documentation.

Credits

The tibs library was created by Scott Griffiths and is released under the MIT License.

The Tibs cat artwork was created by Ada Griffiths and is not covered by the software license. All rights reserved.
